Tamiya Mercedes Benz Arocs 3363 6×4 56352

56352 1/14 Mercedes-Benz Arocs 3363 6×4



1/14 Mercedes-Benz Arocs 3363 6×4

This is a highly accurate 1/14 scale radio control model that recreates the Mercedes Benz Actros 3363 3-axle truck. The Actros series debuted in 2011 and was named 2012 Truck of the Year. Powered by a 15.6-liter inline-6 turbocharged diesel putting out a max of 630hp, the actual 3363 can haul up to 250 tons!

The Tamiya rendition faithfully captures the truck s modern form with the use of ABS plastic body parts and a number of metal chassis components. One look at the detailed interior and auxiliary equipment, such as air tanks, will confirm that the body features replica-quality realism, which is further enhanced with metal transfers depicting emblems and numerous metal-plated parts. The chassis is built for durability as it uses aluminum side channels with resin cross members. Drivability is accomplished by power from the front-mounted motor and is transmitted via a propeller shaft to the rear axle; built-in differential gears guarantee smooth cornering. Gear changes can be made via a separately-sold 4-channel transmitter.

The Actros realism can be further heightened with separately-available trailers that can be attached to its coupler and make the model over a meter in length!

Product Specifications (Specifications subject to change)

Type Detail

Scale 1/14

Construction type Assembly kit

Terrain use On-Road

Drive-train 3-axle semi

Drive type Gearbox

Drive line Dog bone

Differential type Gear

Suspension Leaf spring

Steering mechanism Bell-crank

Shock damper Friction damper

Shock damper material Aluminum

Tire type Rubber

Tire tread Radial

Body material ABS Plastic

Chassis material Aluminum undamp; plastic

Electronic Speed Control (ESC) Not included

ESC model N/A

LED Light buckets Yes

LED lights No

Motor 540-brushed type

Bearings Metal bushings

Adjustable camber Fixed

Adjustable toe angles Front only

Adjustable ground clearance Fixed

Adjustable gear ratio 3-speed transmission

Adjustable wheelbase Fixed

Adjustable track width Fixed

Adjustable shock angle Fixed

Special feature 1 Length: 538mm, Width: 195mm, height: 305mm

Special feature 2 The body of the Actros 3363 is recreated accurately using newly-molded parts differentiating it from the 1851 spec model

Special feature 3 The tried and tested Tamiya 3-axle chassis utilizes a tough ladder frame with aluminum side channels and resin cross members. A realistic drivetrain setup sees the front mounted motor powering twin rear axles.

Special feature 4 3-speed transmission can be controlled via 4ch R/C transmitter. Item 7255252 is the perfect radio to compliment the Actros kit

Special feature 5 Metal leaf spring dampers with built-in coil springs provide durable suspension

Special feature 6 Coupler is included to enable connection with any currently available Tamiya 1/14 scale trailers

Special feature 7 Compatible with the tractor truck option parts (TROP) Items 56531, 56532 and 56536. Use with Multi-Function Control Unit MFC-03 (Item 56523) (or MFC-01, Item 56511) for realistic LED lights and sounds

Special feature 8 Compatible with the tractor truck option parts (TROP) Items 56531, 56532 and 56536. Use with Multi-Function Control Unit MFC-03 (Item 56523) (or MFC-01, Item 56511) for realistic LED lights and sounds

Requires A 4-channel radio gear

Requires B Electronic speed control

Requires C TS plastic model paint

Requires D 7.2 battery undamp; charger

Tamiya nummer: 56352
